UL3239 FEP Wire with 15000V Rated Voltage and 200C High Temperature for Industrial Power Applications

Model Number : UL1858

Brand Name : MYSUN

Place of Origin : Guangdong, China

MOQ : 3050

Conductor Material : Tinned Copper

Diameter : 16 AWG, 18 AWG, 20 AWG, 22 AWG, 24 AWG, 26AWG

Insulation Material : FEP

Rated Voltage : 15000V

Conductor Type : Solid

Shape : Round

Temperature Rating : 200℃

Unit Length : 305/1000

Max Resistance : 14.6 Ω/KM (16 AWG)

Conductor Construction : 19/0.30 (16 AWG)

Nominal Thickness : 1.00 mm

Insulation Diameter : 3.50 mm (16 AWG)

Voltage Rating : 150V

Color Options : All colours

Conductor Options : Tinned copper/Silver-plated copper

Contact Now

Supplies Fortune 500 Companies Top PFA Wire Supplier In China.
UL3239 FEP Wire with 15000V Rated Voltage and 200C High Temperature for Industrial Power Applications
UL3239 FEP Wire with 15000V Rated Voltage and 200C High Temperature for Industrial Power Applications
Specification
UL3239
UL1330
Conductor


Insulation

Max.Cond Resistance（Ω/KM）
Unit length
（M）（Ft）
Size
（AWG）
Construction
（No.mm）
Diameter（mm）
Nominal thickness
（mm）
Diameter（mm）


28
7/0.12
0.36
1.00
2.36
239
610/2000
26
7/0.16
0.48
1.00
2.48
150
610/2000
24
7/0.20
0.60
1.00
2.60
94.2
610/2000
22
19/0.15
0.75
1.00
2.75
59.4
305/1000
20
19/0.19
0.93
1.00
2.95
36.7
305/1000
18
19/0.235
1.17
1.00
3.17
23.2
305/1000
16
19/0.30
1.50
1.00
3.50
14.6
305/1000
14
19/0.37
1.85
1.00
3.85
8.69
305/1000
Click Contact us Get the Best Quote
Company profile
UL3239 FEP Wire with 15000V Rated Voltage and 200C High Temperature for Industrial Power Applications
UL3239 FEP Wire with 15000V Rated Voltage and 200C High Temperature for Industrial Power Applications
Our Products
UL3239 FEP Wire with 15000V Rated Voltage and 200C High Temperature for Industrial Power Applications
Application
UL3239 FEP Wire with 15000V Rated Voltage and 200C High Temperature for Industrial Power Applications
Our Overseas Clients
UL3239 FEP Wire with 15000V Rated Voltage and 200C High Temperature for Industrial Power Applications
Exhibition
UL3239 FEP Wire with 15000V Rated Voltage and 200C High Temperature for Industrial Power Applications
Certifications
UL3239 FEP Wire with 15000V Rated Voltage and 200C High Temperature for Industrial Power Applications
FAQ
1. Who Are We? We Are A Professional Manufacturer Of High-temperature Wires And Cables With 26 Years Of Electric Wire Experience. Our Headquarter Is Located In Shenzhen, Guangdong, China, And Our Two Production Bases Are Located In Dongguan, Guangdong, China And Jingzhou, Hubei, China. 2. What Can We Provide? We Can Provide High-temperature Wires And Cables, Silicone Tubing – Including Silicone Rubber Wire, XLPE, FEP/PFA/ETFE/PTFE Wire, New Energy Cable, Wiring Harnesses. 3. Why Choose Us? A.Free Sample. B.Competitive Price. C.High Quality Standard. D.Customized Service. 4. What Certifications Do We Have？ We Have UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC Certification. 5.What Services Can We Provide? Accepted Delivery Terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU: Accepted Payment Currency: USD, EUR, CNY. Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash.
